Grand Fiberglass Co., Ltd.

Chopped strand Mat is a non-woven reinforced materials，it is made through cutting the continuous Roving．The end products are boats，laminates，bathing equipment，cooling tower，etc．Area weight ranging from 100g/㎡- 900g/㎡．Width can be from 20cm-320cm.Binder is Powder or Emulsion．

E,C specification	Weight g/m	Breaking strength N/150mm	Speed of impregnationS	Package weight kg
E-MCl00	100	30	60	20
E-MC200	200	30	180	30
E- MC350	300	43	180	30
E-MC450	450	60	180	30
E-MC600	600	80	180	30

lt iS made of continuous fiberglass strand．non woven mat containing an insoluble binder for unsatu rated polyester，epoxy，phenolic and
polyurethane resin compatibility in unfilled or filled resin systems lt Is suit for FRP process Iike ltruded ProfiIe．RTM Process．filament winding process，etc．

M2- Stitch Mat,Stitch Bonded Mat,Combo Mat

Stitch-Bonder Combo Mat is a kind of multi-layer fabric made fmm rovings.Each layer is arranged unidirectionly．It is used in extrusion process，hand lay-up and resin Transfer molding(RTM)process．The main end products are boat shells，pipes．Etc

Specitications of Stitched Combo Mat(Multiaxial)

Warp uD(0°) 300-2400gsm,can be with Chopping layer,tapes avaliable
Weft uD(90°) 300-1200gsm,can be with chopping layer,tapes available
Biaxial(0°/90°) 300-2400gsm,can be with chopping layer,tapes available
Double Biaxial(+/-45°) 300—1200gsm,can be with chopping layer,tapes available
Triaxial(0°/+/-45°~or+45°/90°/-45°) 450-1800gsm,can be with chopping layer,tapes available
QuadraxiaI(0°/+45°/90°/45°) 600-2000gsm,can be with chopping layer,tapes available

Chopped strands
Chopped strands are specially designed as reinfome ments for thermoplastic and thermoset resins．It is made to achieve good compatibility with vadous resins such as PA、PBT、PET、PC、PP、ABS and unsaturated PolYester and PhanoIic resins, etc…Cutting length ranging from 3mm一—24mm．
Chopped Strand for BMC BMC Chopped Stands treated with silane—based size，Basic on many different ways，The glass fiber is chopped into different length；with appropriate material，are specially designed as reinforcement for polyester resins． Widely used in automobile parts，home appliances ect．
Chopped Strand for frietion material Chopped Stands treated with silane-based size．Basic on many different ways, The glass fiber is chopped into different length；with appropriate material，are specially designed as reinforcement for phenolic resins Widely used in automobile parts，brake matedal ect

◆ Fiberglass mesh

◆ Drywall tape

◆ High temperature fabric

◆ Composite fiberglass

◆ Various tapes

◆ FRP products
